Dot Line Ceiling Acoustic Panel
Engineered to bring rhythm and refinement to modern interiors, Dot Line is a horizontally formatted acoustic ceiling panel that balances form and performance. With an elongated 1200×600 mm surface and a high NRC of 0.70, it delivers strong echo control and visual fluidity across open-plan ceilings.
Pairs well with
Dot Line Ceiling Acoustic Panel
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
-
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
-
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
-
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
Dot Line – Ceiling Acoustic Panel
Horizontal Harmony. Enhanced Sound Control.
Introducing Dot Line, the acoustic ceiling panel from AcousticMod designed to bring fluidity and rhythm to interior spaces. Its elongated 1200×600mm format creates a continuous visual flow, while its expanded surface area enhances sound absorption for superior acoustic comfort.
Made from 100% polyester (approx. 50% recycled PET), Dot Line offers an NRC of 0.70, making it a reliable solution for reducing echo and controlling noise in large open-plan ceilings, offices, hospitality settings, and modern interiors. Its minimalist yet striking horizontal geometry allows for creative arrangements and modular layouts.
Engineered for easy installation with T-Type, Canopy, and Aluminum Profile systems, Dot Line is fire-rated B-s1, d0, ensuring both safety and performance in commercial or residential applications.
Product Specifications:
-
Brand: AcousticMod
-
Product Name: Dot Line
-
Material: 100% Polyester (Recycled PET approx. 50%)
-
Standard Size: 47.24" × 23.62" × 1.57" | 1200 × 600 × 40 mm
-
Felt Thickness: 0.15" | 4 mm
-
Material NRC: 0.70
-
Total Product Weight: 1200 gr/m² (±5%)
-
Field of Use: For Ceiling
-
Package Size: 48.03" × 24.40" × 2.36" | 1220 × 620 × 60 mm
-
Fire Reaction Class: B-s1, d0
-
Installation Methods: T-Type, Canopy Type, Aluminum Profile Type
Flowing Form. Functional Silence.
Dot Line transforms ceiling spaces into dynamic acoustic landscapes, where horizontal patterns create both visual rhythm and advanced sound performance.
Product Overview
Brand: – AcousticMod
Product Name: – Dot Line Acoustic Ceiling Panel
Color: – Grey, Light Grey, Smoked, Dark Grey
Material: – 100% Polyester (Approx. 50% Recycled PET)
Dimensions: – 1200 × 600 × 40 mm (47.24" × 23.62" × 1.57")
Felt Material Thickness: – 4 mm (0.15")
Carton Weight: – Approx. 1200 gr/m² (±5%)
Packaging & Coverage: – Recommended for horizontal modular ceiling layouts
Field of Use: – Ceiling Only
Package Size: – 1220 × 620 × 60 mm (48.03" × 24.40" × 2.36")
Acoustic Performance
Horizontal Form. Complete Control.
Dot Line delivers an NRC of 0.70, offering reliable acoustic performance for medium to large interiors. Its elongated 1200×600 mm profile increases surface interaction with airborne sound, improving reverberation control and speech clarity across open spaces.
Ideal for offices, lobbies, restaurants, and collaborative zones, Dot Line provides consistent sound absorption while establishing a rhythmic ceiling pattern. Whether aligned in rows or staggered layouts, it brings architectural harmony to acoustic design.
Installation & Compatibility
Designed to Flow. Built to Fit.
Dot Line is optimized for clean, efficient installation in both standard and creative ceiling configurations. Its horizontal orientation and consistent dimensions support linear or staggered layouts, enabling designers to shape sound and space in unison.
Supported installation systems:
- for standard ceiling integration
- for floating or layered acoustic expressions
- for custom framing and precision alignments
Lightweight and adaptable, Dot Line panels ensure fast setup and architectural consistency across new builds or renovation projects.
Design & Material Details
Linear Geometry. Modern Versatility.
Dot Line panels are constructed from 100% polyester felt, with approximately 50% recycled PET, combining sustainability with long-term durability. The 1200×600 mm horizontal format allows for directional ceiling designs, ideal for creating visual flow and rhythm in larger interior spaces.
Available in four refined tones — Grey, Light Grey, Smoked, and Dark Grey — Dot Line supports a variety of design languages, from clean corporate grids to expressive hospitality layouts. Its elongated profile invites modular repetition, seamless transitions, and custom compositions.
Certifications & Sustainability
Sustainable Direction in Acoustic Design
Dot Line is manufactured using low-VOC, fully recyclable polyester felt, with approximately 50% recycled PET, making it an ideal choice for sustainable design projects. It supports green building standards such as LEED® and WELL®, contributing to healthier and more environmentally conscious interiors.
Certified with a B-s1, d0 fire reaction class, Dot Line also ensures low smoke production and high flame resistance, making it a safe and specification-ready solution for commercial and public-use environments where safety is as critical as performance.
Draw the Line Between Sound and Silence
Dot Line brings direction to both form and function. With its extended surface and refined profile, it delivers clarity across open ceilings — turning echo-prone spaces into acoustically balanced environments with a strong architectural identity.
Let Sound Follow the Lines
Engineered to guide both sound and sight, Dot Line transforms ceilings into dynamic compositions. Its linear format absorbs reverberation while establishing rhythm in design, offering control with a continuous visual flow.
Why Choose Dot Line?
Dot Line is more than a sound solution — it's a design element. With its extended format, sustainable construction, and modular flexibility, it brings clarity to interiors and continuity to ceiling design. Ideal for professionals who seek performance and pattern in perfect balance.
Elongated Format for Visual and Acoustic Flow
Dot Line’s 1200×600 mm horizontal layout allows for repeating linear patterns across ceilings, enhancing both spatial rhythm and sound diffusion in large or open areas.
Modular, Creative Layout Potential
Use Dot Line to build grid systems, directional compositions, or alternating arrangements — its geometry supports scalable and expressive configurations in a wide range of interiors.
Sustainable & Fire-Safe Composition
Made from 100% polyester felt with ~50% recycled PET, Dot Line is low-VOC, fully recyclable, and B-s1, d0 fire-rated — combining material responsibility with trusted performance.
FAQs
Need clarity on Dot Line? Here are the most common questions designers and specifiers ask about this horizontally driven acoustic solution.
Please read our FAQs page to find out more.
What makes Dot Line different from other ceiling panels?
Its elongated 1200×600 mm format enables directional layouts that enhance both acoustic efficiency and architectural rhythm — ideal for open-plan and large-scale interiors.
How effective is Dot Line at sound absorption?
Dot Line delivers an NRC of 0.70, offering excellent mid-to-high frequency absorption. It significantly reduces echo and improves clarity in shared environments like offices, hospitality spaces, and conference areas.
Can Dot Line be used in sustainable building projects?
Absolutely. It’s made from 100% polyester, including ~50% recycled PET, and is fully recyclable — supporting compliance with LEED® and WELL® certification frameworks.
What installation options are available?
Dot Line is compatible with T-Type grids, Canopy suspension systems, and Aluminum profile frameworks, making it adaptable to a wide variety of ceiling systems.
Can I use Dot Line as part of a custom ceiling design?
Yes. Its shape is ideal for modular repetition, staggered configurations, or creative layouts — allowing for flexible acoustic expression that complements modern design.
